| Rated input current | 100 A AC |
| Rated output current | 0.1 V AC |
| Accuracy (at 45 to 66 Hz) | Amplitude: ±0.3 % rdg. ±0.02 % f.s. , (45 to 66 Hz, f.s. = rated primary current)
Phase: ±1 ° or less (at 90 A or less), ±1.3 ° or less (at 90 A to 100 A) |
| Frequency characteristics | 66 Hz to 5 kHz (±1 % or less from accuracy) |
| Max. allowable input | continuous 130 A rms (45 to 66 Hz) |
| Max. circuit voltage | 300 V AC rms (insulated wire) |
| Core jaw dia. | Ø15 mm(0.59 in) |
| Dimensions, mass | 46 mm(1.81 in)W × 135 mm(5.31 in)H × 21 mm(0.83 in)D, 230 g (8.1 oz), cord length: 3 m(9.84 ft) |
