Output Ratings (@ 0°C to 40&d

• Voltage: 0 to 35 V /1.4 A
• Current: 0 to 60 V / 0.8 A

Programming Accuracy (@ 25°C

• Voltage: <0.05% + 10 mV (<0.1% + 25 mV for output 2 of E3646/47/48/49A)
• Current: <0.2% + 10 mA

Ripple & Noise 20 Hz to 20 MHz

• Normal Mode Voltage: <5 mVpp / 0.5 mVrms for 8 V / 20 V models, <8 mVpp / 1 mVrms for 35 V / 60 V models
• Normal Mode Current: <4 mArms
• Common Mode Current: <1.5 uArms

Readback Accuracy (@ 25°C &pl

• Voltage: <0.05% + 5 mV (<0.1% + 25 mV for output 2 of E3646/47/48/49A)
• Current: <0.15% + 5 mA (<0.15% + 10 mA for output 2 of E3646/47/48/49A)
