0 to 35 Vdc

0 to 15 A

Programming accuracy: 15 mV / 0.06%

Load regulation: 3 mV / 0.5 mA

Ripple & noise (rms/p-p): 0.4 mV / 4 mV

Auto-parallel up to three units

Outputs can be connected in parallel or in series

Programmable over-voltage and over-current protection

Over-temperature protection

Discrete Fault Indicator/Remote Inhibit (DFI/RI)

Self-test occurs at power-on from an GPIB command

User definable power-on state

VXI plug & play drivers

104 to 127 Vac; 47-63 Hz operation

Weight: 54 lb; Size: 133 mm (5.25 in)H x 426
