Features
10nV sensitivity
10nV/°C stability
Analog output
6½-digit resolution
Fully programmable
Standard IEEE-488 interface
Pushbutton zero
General Specifications
Display | Seven 0.5" LED digits with appropriate decimal point and polarity |
Input Capacitance | 5000pF on mV ranges |
Settling Time | 0.5s to within 25 counts of final reading with Filter on, Damping off |
Filter | 3-pole digital; RC = 0.5, 1, or 2 seconds depending on range |
Conversion Speed | 4 readings/second |
Analog Output | Accuracy: ± (0.15% of diplayed reading = 1mV). Time Constant: 400ms Level: +2V full scale on all ranges; x1 or x1000 gain. |
Overload Indication | Display indicates polarity and OFLO |
Analog Output | ±2V full scale on all ranges |
Isolation | Input LO to Output LO or power line ground: 1400V peak |
Input Connectors | Special low thermal for 200mV and lower ranges. Binding posts for 2V to 1000V ranges |
DC Volts
Range | 5½-Digit Resolution |
2 mV | 10 nV |
20 mV | 100 nV |
200 mV | 1 µV |
2 V | 10 µV |
20 V | 100 µV |
200 V | 1 mV |
1000 V | 10 mV |
