Maximum indication: 319999
Maximum sampling: 1000 cycle/s (BURST)
Data memory: 10000 data
Measurement function: AC measurement performance 0.06%
Interface: GPIB/RS232 equipped as standard
Function
DCV: 30 mV to 1000 V
2W /4W: 30 ? to 300 MOhm
LP2W /LP4W: 300 to 30 MOhm
DCI: 3 mA to 3 A
ACV: 300 mV to 700 V
ACV (AC+DC): 300 mV to 700 V
ACI: 3 mA to 3 A
ACI (AC+DC): 3 mA to 3 A
Frequency: 1 Hz to 300 kHz
Display function: 7-segment/fluorescent character display tube
Open terminal voltage: Max. 8 V
Min. resolution
DC voltage: 0.1 µV
AC voltage: 1 µV
Resistance: 100 µOhm
Sampling rate: 1000/100/20/5 cycle/s
Measuring rate: Fast/Med/Slow/Long-It
Sampling mode: Free/Hold/Burst
