DC Volts - 5 ranges: 0.1 V to 1000 V
- 8-1/2 to 4-1/2 digits resolution
- Up to 100,000 readings/s (4-1/2 digits)
- Maximum sensitivity 10 nV
- 0.6 ppm 24-hour accuracy
- 8 ppm (4 ppm optional)/year voltage reference stability
Resistance - 9 ranges: 10 ohms to 1 Gohms
- 2-wire and 4-wire measurements with offset compensation
- Up to 50,000 readings/second (5-1/2 digits)
- Maximum sensitivity 10 micro-ohms
- 2.2 ppm 24-hour accuracy
AC Volts - 6 ranges: 10 mV to 1000 V
- 1 Hz to 10 MHz bandwidth
- Up to 50 readings/s with all readings to specified accuracy
- Choice of sampling or analog true rms techniques
- 100 ppm best accuracy
| DC Current - 8 ranges: 100 nA to 1 A
- Up to 1,350 readings/s (5-1/2 digits)
- Maximum sensitivity 1 pA
- 14 ppm 24-hour accuracy
AC Current - 5 ranges: 100 µA to 1 A
- 10 Hz to 100 kHz bandwidth
- Up to 50 readings/second
- 500 ppm 24-hour accuracy
Frequency and Period - Voltage or current ranges
- Frequency: 1 Hz to 10 MHz
- Period: 100 ns to 1 second
- 0.01% accuracy
- AC or DC coupled
Features - Math and Statistics
- 20 kB memory
- Self-adjusting autocalibration
- Up to 100,000 readings/s over GPIB or with internal memory
|
