20 MS/s (50 ns) Clock Rate Provides up to 10 MHz Waveforms

Up to Four Channels of 64 k Record Length

12-Bit (1/4096) Vertical Resolution

Direct DSO Waveform Transfers

Region Shift Provides 50 ps Edge Placement

24-Bit Channel, TTL Digital Data Generator (Opt. 04)

Linear, Log and User Definable Sweep Generation TBR (Opt. 05)

Built-in 1.44 MB, 3.5 in. Floppy Disk

FFT Editor (Opt. 09) Frequency Domain Editing

Real-time Waveform Sequencer to Easily Create Automatic Test Sequences and

    Extremely Long Patterns

Formula Entry Waveforms

Fully Programmable from Front Panel, RS-232 and GPIB (IEEE 488.2)
