Features:
- Includes both RS-232C and IEEE-488 interfaces
- Six-digit vacuum fluorescent display
- Stores and recalls up to 10 configurations
- System calibration is user-adjustable
- Provides trigger in/out control with alarm levels
Specfications
Display | 6-digit vacuum fluorescent |
Sampling Resolution | 20,000 count <25 Hz, 4096 count <1 kHz |
Gain Ranges | Up to 7 decades |
Current Sensitivity (full-scale) | 2.5 nA - 2.5 mA |
Resolution | 100 fA |
Sampling Rate | Up to 1 kHz single-channel, Up to 500 Hz dual-channel |
Bandwidth (-3 dB) | DC to 47 kHz |
Analog Output | 0 - 2.5 V into 50 ohm |
DC Accuracy | <±0.1% typical |
Power Requirements | 90 to 240 VAC |
