Two Channels:: | Enable the unit to support up to two testing instruments with independent or tandem configurations. |
Built-in Alarm System: | For power, speed, torque, temperature, air flow, water flow, electrical overload and external inputs |
Torque/Speed Analog Outputs: | For interface with a data acquisition system or strip chart recorder |
Two Standard Computer Interfaces: | RS-232 and IEEE-488 |
High Speed Data Acquisition: | 120 torque and speed points per second via IEEE bus
(approx. 60/sec. via RS-232) |
High Quality, Easy-to-Read Vacuum Fluorescent Readout: | Displays torque, speed, power, auxiliary and PID (proportional gain, integral and derivative) values |
Fast Full-Curve Data Acquisition: | Free-run to locked rotor in seconds |
Speed & Torque Operating Modes: | Provide independent PID settings for improved Dynamometer control |
Built-in Current Regulated Supply: | For use with Hysteresis Dynamometer only |
Adjustable Torque Units: | English, Metric and SI are standard |
Dynamometer Overload Protection | --- |
Digital Filter: | Removes undesired noise from torque signals |
Cross Loop Function: | Allows closed loop control of brake via torque transducer |
Programmable Digital PID Values: | Controlled and stored via M-TEST software or controlled manually |
Saving: | Saves programmed values within configuration |
Auxiliary ± 10 VDC Analog Input: | For additional transducer |
Single or Multi-point Torque and Speed Stabilized Testing: | Via M-TEST software |
Calibration: | Closed box calibration |
Rack Mounting: | 19 in (482.6 mm) rack mounts with handles |
