Built-in Voltage Source: ±20 V @ 2 mA voltage source with lO mV resolution

Bias Waveforms: DC, square wave, and staircase voltage bias waveforms  allow the user to make stepped current or capacitance

   measurements, as well as DC current measurements

Voltage Steps-In ±lO mV, 2O mV, 5O mV, and 1OO mV gradations at 0.07 to 199.99 sec intervals in O.Ol sec increments

Q/t Measurement: Q/t monitors current during capacitance measurement

Compensates for Error Currents - Selectable capacitance correction for leakage current errors

4.5 Digit LED Display

Zero Correct-A front panel zero correct control allows the user to cancel offsets internal to the Model 595

Reading Modifiers-Baseline suppression and C/C, normalization of readings

Standard IEEE-488 Interface--The built-in interface allows full bus operation of the Model 595

CV and IV Outputs--Built-in C, Q/t or I vs. V analog outputs (with automatic pen lift) or IEEE-488 digital plotter output

Digital Calibration: The instrument may be digitally calibrated from the front panel or over the IEEE-488 bus
