Specifications

• Display:  0.5 in LED digits, 4½-digit signed mantissa, 1-digit signed exponent.
• Maximum Allowable Common Mode Voltage (Output or Output Common to Chassis):   250 V rms, DC to 60 Hz.
• Increment/Decrement:  Automatic, manual or trigger modes.  Range of Dwell Times:  50 ms to 999.9 s.
• Output Load:  Output load must be non-inductive.
• External Trigger:  TTL-compatible External Trigger Input and Output.
• Output Connections: Teflon^® insulated 2-lug triax connector (specialty connector 30JR121-1) for output; five way binding posts for GUARD, OUTPUT COMMON and CHASSIS GROUND; BNC (chassis isolated) connectors for EXTERNAL TRIGGER INPUT and OUTPUT.  All connections on rear panel.
• Accessories Supplied:  Model 6011 Triaxial Test Lead (3ft)




  Range	Maximum Output	Step Size
  100 mA	± 101.00 mA	50 µA
  10 mA	± 19.995 mA	5 µA
  1 mA	± 1.9995 mA	500 nA
  100 µA	± 199.95 µA	50 nA
  10 µA	± 19.995 µA	5 nA
