| Measurement ranges and Accuracy | 30 mΩ to 3 k-Ohm, 6 ranges, ±0.5 % rdg. ±8 dgt. (all ranges)
In the case of MEDIUM: Add 3 dgt. to the above dgt. error. In the case of FAST: ±0.5 % rdg. ±8 dgt. (30 mΩ), ±0.5 % rdg. ±6 dgt. (other ranges), However, in the case of FAST, the display counter decreases 4 digits in all ranges. |
| Measurement current | 7.4 mA (30 mΩ range) to 1.5 µA (3 k-Ohm range) |
| Max. applied measurement voltage | 60 V DC (AC input is not possible) |
| Sampling speed | 50 times/s (FAST) to 1.56 times/s (SLOW) at 50 Hz mode
60 times/s (FAST) to 1.88 times/s (SLOW) at 60 Hz mode |
| Display | 31,000 full digits (resistance), 50,000 full digits (voltage), Fluorescent tube |
| Measurement method | 1 kHz AC four-terminal measurement |
| Open-circuit terminal voltage | 20 mV peak max. (30 mΩ to 3 k-Ohm all ranges) |
| Comparator functions | Setting: Upper and lower limit, Up to 30 tables
Output: 3 levels (Hi, In, Lo) or (Pass, Fail), Open-collector, display, beep sound |
| Interface | RS-232C (standard), GP-IB or External printer (option) |
| Power supply | 100 to 240 V AC (50/60 Hz) |
| Dimensions, mass | 215 mm(8.46 in)W × 80 mm(3.15 in)H × 320 mm(12.6 in)D, 2.1 kg (74.1 oz) |
| Accessories | CLIP-TYPE LEAD 9287 (1), Power cord(1) |
