• Measurement Parameters: |Z|, |Y|, θ, R, X, G, B, L, C, D, Q. 20 parameter combinations are available.
• Test Frequency: 100 Hz - 40 MHz (cable length: 0m), 100Hz - 15 MHz (cable length: 1m), 1mHz resolution
• OSC Level: 10 mV - 1Vrms (≤10MHz), 10mV - 0.5Vrms (> 10MHz), 3 digit resolution
• DC Bias:0 - +40V, 10mV resolution
• Measurement terminal: 4 - terminal pair configuration
• Measurement Range and Max. Resolution:


  Measurement Parameter	Range	Max. Resolution
  |Z|, R, X	10mΩ to 100MΩ	100μΩ
  |Y|, G, B	10nS to 100S	1nS
  θ	+ 180°	0.01°
  L	1nH to 100kH	10pH
  C	10fF to 0.1F	0.1fF
  D	0.001 to 10	0.0001
  Q	0.1 to 1000	0.1

• Basic Measurement Accuracy: 0.17%

Gain-Phase Measurements

• Measurement Parameters: Tch/Rch (dB, Linear Ratio), Tch, Rch (V, dBm, dBV), θ(degree, rad), τ
  Tch = Test Channel, Rch = Reference Channel, τ = Group Delay
• Measurement Frequency: 10 Hz - 100MHz, 1mHz resolution
• APerture Frequency Range (Group Delay Measurements): 0.5% - 100% of frequency span
• OSC Level: -65dBm - + 15dBm, 0.1dB resolution
  Measurement Range:
  Tch/Rch: 0 - +120dB, 0.001dB resolution
  Tch/Rch: -107dBm - -5dBm (+dB Attenuator); -87dBm - +15dBm (20dB Attenuator); 0.001dB resolution
  θ: +180° (can display phase continuously with the phase scale expansion function), 0.01° resolution
  τ: 0.1ns - 1s, 0.1ns resolution
• Basic Measurement Accuracy:
  Tch/Rch: 0.1dB, 0.5°
  Tch/Rch: 0.35dBm
  θ: 0.5°
