제품명

Isolation Amplifier

제조사

모델

5323

가격

문의요(재고유)

렌탈

문의요

Isolation voltage	AC7000Vpeak, 48Hz to 62Hz, 1 min. AC2800Vpeak, 48Hz to 62Hz, continuous DC± 2000V, continuous
IMRR	180dB or greater (DC and 60Hz, gain = X 1000)
Gain	X 1 to X 1000, 1-2-5 step
Gain accuracy	± 0.2%/FS or less (1kHz, no load)
Frequency range	DC to 1MHz
Noise	15nV/√Hz typ., 20nV/√Hz or less (1kHz)
Low pass filter	1k, 10k, 100kHz and THRU, 12dB/oct. PL(Phase Linear)
Power requirements	AC100V, 120V, 220V or 240V switchable 48to 62Hz, approx. 15VA
Dimensions	215(W) X 88(H) X 350(D) mm
Weight	Approx. 3.2kg
