Measurement ranges and Accuracy | 0mΩ to 30kΩ, 7 Ranges, 3500 Full Digits ±0.1 % rdg. ±6 dgt. (30mΩ, 3Ω Range) ±0.1 % rdg. ±4 dgt. (300mΩ, 30Ω to 30kΩ Range) |
| Measurement current | 100 mA (30mΩ, 300 mΩ Range) |
| Max. applied measurement | 3.5 mV DC (30 mΩ Range) to 350 mV DC (30kΩ Range) |
| Sampling Speed | Fast: 16 times/second Slow: 4 times/second |
| Response Time | Fast: 100ms Slow: 300ms |
| Display | 3500 full digits, Liquid Crystal Display |
| Measurement method | Four-terminal measurement |
| Open-circuit terminal voltage | 4.0 V Max. (30 mΩ to 30 kΩ all ranges) |
| Digital input/output (-01, -02 and -03 Ver. only) | TTL output BCD, or other inputs/outputs for external control |
| Comparator functions | Setting:Upper and lower limit, or reference value and % for resistance, Up to 7 tables beep sound |
| Power supply | LR6 (AA) or R6P (AA) × 6, or (OPTIONAL) 9445-02, -03 AC ADAPTER (9 V, 1.4 A) |
