Wide bandwidth : DC to 10MHz
High gain : 10 to 1000
Differential input (single-ended configuration also selectable)
High CMRR : 120dB or higher
High common mode voltage : ± 10V
Low noise : 4nV/√Hz.typ. (1kHz)
| Input configuration | Balanced differential input (2 BNC connectors) |
| Input impedance | 1MΩ ± 2% (100M ohm impedance is available) |
| Gain | 10 to 1000(With 50Ω load) in 1, 2, 5 sequence |
| Power requirements | AC100, 120, 220 or 240V switchable |
| Dimensions(mm) | 215(W) X 88(H) X 350(D) |
| Weight | Approx. 3.2kg |
