0 to 0.12 ohms/0 to 0.6 ohms

Test current can be set to any desired value (3 to 30A)

Equipped with various signal output terminals

Equipped with PASS-FAIL judgement

Resistance Measurement Value: 0 to 0.12 ohms/0 to 0.6 ohms, 2 ranges

Test current output: 3 to 30A, AC

PASS-FAIL judgement: Judged FAIL when measure value is greater than

    reference value. Judged PASS if there are no abnormalities after the set amount of time has passed

Test Time: 0.5 sec to 10 min

Signal Output: TEST, PASS, FAIL, WARNING, READY, MONITOR

Dimension (mm): 430 W x 149 H x 370 D

Weight: approx. 16kg
