Key Features

•Internal light source (single 1550nm, )
•Uses Mueller Method
•Measurements take only a few seconds
•External tunable source capability
•GPIB and RS232 remote control
•Integrated PDL standard source

Applications
•Passive component qualifications
•Optical Attenuator Specifications
•Optical switch specifications

SPEC
Built-In Laser Type (Fabry Perot):  1550 nm
Fiber Type:  9 / 125 µm SM
PDL and Average Loss Measurements:
    Resolution:  0.01, 0.001, or 0.0001 dB
    Optimization:  1550 nm
    Absolute Accuracy PDL 1455-1665 nm
          (maximum):  ± (0.005 dB + 5% of PDL) dB
          (typical):  ± (0.002 dB + 1% of PDL) dB
    PDL 1250 - 1350 nm
           (maximum):  ± (0.010 dB + 5% of PDL) dB
           (typical):  ± (0.004 dB + 2% of PDL) dB
    Lav (insertion loss):
           ± (0.05 dB + 2% of Lav) dB
           ± 0.25 dB at -10 dBm
    Repeatability: (PDL):
           ± (0.001 + 5% of PDL) dB
    Lav accuracy:
           ± (0.001 + 2% of Lav) dB
    Dynamic range1: PDL range2:  0-5 dB
    Lav (insertion loss) (InGaAs 3 mm):  >60 dB
FC Connector
