0.05% basic accuracy
Universal application: single-phase, three-phase, and DC rectifier measurements
Harmonic analysis of voltage current and power on each phase and neutral to the 99th harmonic
Accurate with distorted waveforms and poor power factors
Built-in integrator for measuring energy maximum demand or averaged values
Exceptionally wide input ranges on voltage (0.2 to 2000Vpk) and current (10mA to 200 Apk)
Measures short term events, such as start-up current and burst power
Accepts inputs directly or from external shunts, current transformers and voltage transformers
Provides eight programmable outputs for chart recorders or scopes
Wide frequency range: -DC to 1MHz
Full system capability with IEEE488.2, RS232 and Centronics interfaces as standard
| Voltage (V) | Ranges (Auto or Manual) (12 ranges 1-2-5 sequence): | 0.5 V to 2000 Vpk (1400 Vrms) |
| Frequency Range: | DC and 0.1 Hz to 500 kHz | |
| Current (A) Ranges (Auto or Manual) (12 ranges 1-2-5 sequences) | INT: | 0.05A to 200Apk (30A rms) |
| EXT: | 6.25mV to 2.5pK (1.5Vrms) | |
| Power (W) Ranges (Auto or Manual) (144 ranges corresponding to V and A) | 25mW to 400kW pk (with scaling to 100,000MW) | |
| Apparent Power (VA) Ranges (Auto or Manual) (144 ranges corresponding to V and A) | 25mVA to 400kVA pk (with scaling to 100,000MVA) | |
| Reactive Power (VAR) Ranges (Auto or Manual)(144 ranges corresponding to V and A) | 25mVAr to 400kVArpk (with scaling to 100,000MVAr) | |
| Power Factor (PF) Range | ±0.000 to ±1.000 | |
| Crest Factor Range | 1.000 to 19.999 | |
| Inrush Current Range | 0.1A to 200Apk (with scaling to 20 MA) | |
| Impedance Range | 0.0001 Ω to 9.999 MΩ | |
| Frequency Range | Internal Source 5Hz to 1MHz | |
| Harmonic Analysis Range | DC and Fundamental to 99th harmonic for voltage and current. Maximum harmonic = 1MHz | |
| Integrator Range | 0.001 W.hr to 100,000MW.hr | |
