Features:

• Low-profile design (44 mm or 88 mm)
• Voltage and current presetting
• Simultaneous voltage and current display
• Remote control using external voltage
• Remote control using an external resistor
• Output ON/OFF control




  Model	Specification
  PVS7.5-140	0 to 7.5V / 0 to 140A
  PVS7.5-140 (With GPIB)	0 to 7.5V / 0 to 140A, Equipped with GPIB interface
  PVS7.5-300	0 to 7.5V / 0 to 300A
  PVS7.5-300 (With GPIB)	0 to 7.5V / 0 to 300A, Equipped with GPIB interface
  PVS12-100	0 to 12V / 0 to 100A
  PVS12-100 (With GPIB)	0 to 12V / 0 to 100A, Equipped with GPIB interface
  PVS12-220	0 to 12V / 0 to 220A
  PVS12-220 (With GPIB)	0 to 12V / 0 to 220A, Equipped with GPIB interface
  PVS20-60	0 to 20V / 0 to 60A
  PVS20-60 (With GPIB)	0 to 20V / 0 to 60A, Equipped with GPIB interface
  PVS20-130	0 to 20V / 0 to 130A
  PVS20-130 (With GPIB)	0 to 20V / 0 to 130A, Equipped with GPIB interface
  PVS40-30	0 to 40V / 0 to 30A
  PVS40-30 (With GPIB)	0 to 40V / 0 to 30A, Equipped with GPIB interface
  PVS40-70	0 to 40V / 0 to 70A
  PVS40-70 (With GPIB)	0 to 40V / 0 to 70A, Equipped with GPIB interface
  PVS60-20	0 to 60V / 0 to 20A
  PVS60-20 (With GPIB)	0 to 60V / 0 to 20A, Equipped with GPIB interface
  PVS60-46	0 to 60V / 0 to 46A
  PVS60-46 (With GPIB)	0 to 60V / 0 to 46A, Equipped with GPIB interface
  PVS100-12	0 to 100V / 0 to 12A
  PVS100-12 (With GPIB)	0 to 100V / 0 to 12A, Equipped with GPIB interface
  PVS100-28	0 to 100V / 0 to 28A
  PVS100-28 (With GPIB)	0 to 100V / 0 to 28A, Equipped with GPIB interface
  PVS150-8	0 to 150V / 0 to 8A
  PVS150-8 (With GPIB)	0 to 150V / 0 to 8A, Equipped with GPIB interface
  PVS150-18	0 to 150V / 0 to 18A
  PVS150-18 (With GPIB)	0 to 150V / 0 to 18A, Equipped with GPIB interface
  PVS300-4	0 to 300V / 0 to 4A
  PVS300-4 (With GPIB)	0 to 300V / 0 to 4A, Equipped with GPIB interface
  PVS300-9	0 to 300V / 0 to 9A
