Specifications

- Wavelength Range: 1475 to 1575 nm
- Wavelength Resolution: 0.001 nm at 1550 nm
- Optical Output Level: > +1 dBm (typ.)
- Fiber Type: 9/125 um SMF

Additional Information

- Spectral Linewidth: 100 KHz (typ., coherent control OFF)
                      50-500 MHz (typ., coherent control ON at 1500-1570 nm)
- Optical Power Stability: +/- 0.03 dB
- Wavelength Accuracy: +/- 0.1 nm

Options

- Option 003: built-in optical attenuator, 40 dB attenuation
- Option 007: Polarization maintaining fiber,
              Panda-type, for straight or angled connector types
              (cannot be combined with option 003 or 023).
- Option 021: straight contact connector
- Option 022: angled contact connector
- Option 023: Diamond HMS-10/HP/HRL angled,
              non-contact connector
              (cannot be combined with option 007)
