제품명
Optical Spectrum Analyzer
제조사
Anritsu
모델
MS9780A
가격
문의요
렌탈
문의요
첨부파일
상세내용
- -70 dB dynamic range
- -90 dBm guaranteed optical reception sensitivity
- Tracking with tunable laser source
- Optical pulse measurement
- Full range of WDM application functions
Specification | Value |
Wavelength range | 600 to 1750 nm |
Wavelength Accuracy | ±0.05 nm (1550 ±20 nm, resolution: 0.07 to 0.2 nm, after calibration with wavelength reference light source option) |
Resolution | 0.07nm (min., SM Fiber) |
Level measurement range | (attenuator: off) -90 to +10 dBm (1250 to 1600 nm) |
Dimensions and mass | 320(W) x 177(H) x 350(D)mm, less than 16.5 kg |
