Specifications

25 mW / 658 nm

Center wavelengths                             370 ~ 517 nm*
                                                   632 ~ 1770 nm*
Typical power range                             3 ~ 300 mW
Typical coarse tuning range                     2 ~ 100 nm
Typical mode-hop free tuning range            20 GHz
Typical linewidth (5 µs integration time)         100 kHz ~ 1 MHz
Typical output beam characteristics            3 mm x 1 mm
Typical output beam polarization Linear        > 100:1
Fiber coupling efficiency**: min. (typ.)         55 (65) %
Fiber coupling efficiency with APP**: min.     (typ.) 65 (75) %
Typical long term frequency change with room temperature 400 MHz / K
Environmental temperature (operating)        15 ~ 30 °C
Environmental temperature (transport)        0 ~ 40 °C
Humidity Non condensing
Operating voltage                              100 .. 120V/220 ~ 240VAC, 50 ~ 60Hz
Power consumption Typ.                      < 100 W, max. 300 W
