Specifications. Range: 0-200 mA, 0-500 mA.

Setpoint Resolution: 4 µA (200 mA), 10 µA (500 mA).

Setpoint Accuracy: ±100 µA (200mA), ±250 µA (500mA).

Compliance Voltage (fixed): 6.55 V maximum.

Temperature Coefficient: <50 ppm/°C.

Short-Term Stability (10 min.): <20 ppm.

Long-Term Stability (24-hour): <50 ppm.

Noise and Ripple (rms) High Bandwidth Mode: <4 µA.

Worst case transients (power line induced): <5 mA.

Photodiode Feedback; Range: 5 to 5000 µA.

Output Stability: ±0.02%.

Setpoint Accuracy: ±2.5 µA.

Bias Voltage: 0-5 V reverse bias.

Laser drive current display; Output current range: 0.00-200.00 mA, 0.00-500.00 mA.

Output current resolution: 0.01 mA.

Output current accuracy @ 25°C: ±0.1 mA (200 mA), ±0.25 mA (500 mA).

TEC Output; Output Type: Bipolar, constant current source.

Compliance Voltage: 4 volts at 4 amps.

Maximum Output Current: 4A. Maximum

Output Power: 16 W.

Current Noise and Ripple: <1 mA rms.

Temperature Control Range: -99°C to 150°C, -20°C to 70°C with typical 10 K thermistor.
