KEY FEATURES

• Simultaneously measures wavelength and power of up to 1000 discrete optical signals.

• Optical wavelength measured to an accuracy as high as ± 0.3 pm.

• Continuous calibration with a built-in wavelength standard.

• Measurement confidence level of ≥ 99.7%.

• Traceable to NIST standards.

• Power measured to an accuracy of ± 0.5 dB.

• Automatically calculates OSNR to > 40 dB.

• Operation from 1270 to 1650 nm covers the important C and L optical bands.

• Measurement rate of 4 Hz.

• High sensitivity of -40 dBm (0.1 µW) with automatic electronic gain control.

• Operates with CW and modulated signals.

• Convenient front panel display reports measurement data in a variety of formats.

• Interfacing via SCPI using USB, Ethernet, or GPIB.

• Rugged design for manufacturing environments.
