제품명
OSICS with DFB Module 8ch
제조사
Anritsu
모델
OSICS DFM
가격
문의요(재고유)
렌탈
문의요
첨부파일
상세내용
Module: OSICS-DFB
ITU wavelength: 1587.463nm, 1588.304nm, 1589.146nm, 1589.989nm,1590.833nm, 1591.678nm, 1592.523nm, 1593.369nm
Wavelength tuning range: 1.6nm(1.8 typ)
Accuracy: ±0.03nm
Setting Resolution: 0.001nm
Stability: ±0.005nm/h(+-0.005nm/24h typ)
Output Power: +13dBm
Stability: ±0.01dB
Spectral Width(FWHW): <30MHz
Relative Intensity Noise: >145dB/Hz(typ)
Optical Connector: FC/APC
Output Fiber: Polarization maintaining Fiber
Optical Isolation: 35dB
Returen Loss: -60dB
Analog Modulation:150Hz to 1GHz(External Modulation)
Digital Modulation:1Hz to 1MHz(Internal/External)
Main frame;
Size: 448-133-370mm
Weight: 8.1kg
Power Source: 100 to 240V,50/60Hz
Interface: RS-232C,IEEE-488.2
Slot: 8Ch
