Form Factor: Benchtop

Fiber Type: Singlemode

Minimum Wavelength: 600 nm

Maximum Wavelength: 1700 nm

Minimum Wavelength Resolution: 0.01 nm

Maximum Wavelength Resolution: 0.5 nm

Minimum Span: 0.2 nm

Maximum Span: 1100 nm

Minimum Input Decibel: -87 dBm

Maximum Input Decibel: 23 dBm

Maximum Dynamic Range: 67 dB

Minimum Sweep Time: 500 ms

Connector type: (main signal) FC

For analysis of DWDM Optical Components and Systems

Passive Component & Filter Analysis

Opt. Amplifier Analysis

Pass/Fail Analysis

Pulse Light Measurement

DWDM Analysis for 256 channels

OSNR Measurement

Power Level Measurement Accuracy: 0.4 dB (1550nm)

Wavelength Measurement Accuracy: 20pm (1530nm to 1570nm)
