제품명
Laser Diode Controllers
제조사
ILX Lightwave
모델
LDC-3714B
가격
문의요(재고유)
렌탈
문의요
첨부파일
상세내용
Features
- Laser Diode Current Source with Integrated 32W Temperature Controller
- GPIB/IEEE-488 Remote Interface
- High Stability, Low Noise Laser Current Source Operating in Constant Power or Constant Current Modes
- Analog Modulation Capability to 1MHz
- 4-Wire Laser Forward Voltage Measurement and Adjustable Voltage Limit
- Temperature Controller Compatible with Thermistor, IC, and RTD Temperature Sensors
- Temperature Stability of ±0.004°C
- TE Voltage Measurement
Description
The ILX Lightwave LDC-3700B Series Laser Diode Controllers are an industry-leading family of high performance, microprocessor- based instruments that offer a high stability, low noise current source with an integrated 32W temperature controller specifically designed for controlling the current and temperature of laser diodes. These controllers are known throughout the industry for their reliability, precision, and ease-of-use.
The LDC-3714B, LDC-3724B and LDC-3744B cover a wide range of low to medium power laser diode testing and control applications. The LDC-3714B and 3724B are targeted specifically for precision control of low to medium power laser diodes with dual range current sources of 50/100mA and 200/500mA respectively. For higher power laser diodes, the LDC-3744B provides a dual range current source of 2/4A. The LDC-3714B, LDC-3724B and LDC-3744B come with an integrated 32W temperature controller.
Independent power supplies for laser and TE current provide clean, isolated power for laser protection and stability. All of ILX Lightwave’s proven laser diode protection strategies including slow start, adjustable current limit and compliance voltage, intermittent contact protection, and output shorting relays are incorporated into each model.
The LDC-3714B, LDC-3724B and LDC-3744B cover a wide range of low to medium power laser diode testing and control applications. The LDC-3714B and 3724B are targeted specifically for precision control of low to medium power laser diodes with dual range current sources of 50/100mA and 200/500mA respectively. For higher power laser diodes, the LDC-3744B provides a dual range current source of 2/4A. The LDC-3714B, LDC-3724B and LDC-3744B come with an integrated 32W temperature controller.
Independent power supplies for laser and TE current provide clean, isolated power for laser protection and stability. All of ILX Lightwave’s proven laser diode protection strategies including slow start, adjustable current limit and compliance voltage, intermittent contact protection, and output shorting relays are incorporated into each model.
Specifications
ILX Lightwave LDC-3700B Series Laser Diode Controllers Specifications | |
LDC-3714B | 50/100mA Laser Diode Controller |
LDC-3722B | 200/500mA Laser Diode Controller |
LDC-3724B | 200/500mA Laser Diode Controller |
LDC-3742B | 2/4A Laser Diode Controller |
LDC-3744B | 2/4A Laser Diode Controller |
