Input chennel
DX102(2channel) DX204(4channel)
DX104(4channel) DX208(8channel)
DX106(6channel) DX210(10channel)
DX112(12channel) DX220(20channel)
DX230(30channel)

측정주기:
DX102,DX104,DX204,DX208 : 125ms
DX106,DX112,DX210,DX220,DX230 : 1sec.

Input unit,Range
DCV :20mV, 60mV,200mV,2V,6V,20V
TC :R,S,B,K,E,J,T,N,W,L,U
RTD :Pt100, JPT100
DI:Voltageinput(Off:2.4V이하/On:2.4V이상)

Disply형식:
Trend,Bar,graph,numeric,Overview Information Disply

Data 저장 방법 :Manual, Auto saving

External Dimensions:
DX100 약 151.1(W)*151.1(H)*218(D)mm
DX200 약 294.6(W)*294.6(H)*220(D)mm
