제품명
Signal Generator
제조사
HP/Agilent/KEYSIGHT
모델
8648A
가격
문의요(재고유)
렌탈
문의요
첨부파일
상세내용
Frequency range: 100 kHz to 1000 MHz
Frequency resolution: 0.001 Hz
Absolute accuracy: ±3x10-6 x carrier frequency
Output power range: +10 dBm -136 dBm
Output accuracy: ±1.0 dB
SSB phase noise (at 20 kHz offsets): -116 dBc/Hz
Non-harmonic spurious signals: -60 dBc (output <+4 dBm)
Internal AM, FM, phase modulation
HP-IB interface
Output connector: N(f)
90 - 264 Vac; 48-440 Hz operation
Weight: 20 lb; Size: 165 mm (6.5 in)H x 330 mm (13.0 in)W x 368 mm (14.6 in)D
