제품명
Pulse Generator
제조사
BNC (Berkeley Nucleonics Corporation)
모델
555
가격
문의요(재고유)
렌탈
문의요
첨부파일
상세내용
| Configuration: | 2 channels of delays and widths per instrument | ||||||||||
| Timing Delays and Widths: |
| ||||||||||
| Trigger Modes: | External Trigger, External Gate, Internal(continuous), single shot burst, duty cycle | ||||||||||
| External Trigger/Gate: | Opto-isolated input circuitry.
| ||||||||||
| Internal Rep Rate Generator: |
| ||||||||||
| Single Shot: | Pushbutton provides a single trigger | ||||||||||
| Burst: | May be pushbutton or external trigger initiated. Each channel may provide a burst from 1 to 50,000 pulses at the internal rep rate. The Burst mode is selectable for each channel and each of those channels may have an independent number of pulses. | ||||||||||
| Duty Cycle: | This mode allows the timing events to ON for a specific duration and then OFF for another specific duration. The ON/OFF cycles can be counted and then terminated after a specified number of cycles | ||||||||||
| Outputs: | Selectabe, a fixed amplitude TTL/CMOS or adjustable level to 12V, Optional 35V output | ||||||||||
| Impedance: | 50 ohm | ||||||||||
| Adjustable Amplitude: |
|
